Belangrijkste specificaties
- Materialen Koper, Nikkel
-
Kleur
Zilver -
LED verlichting
Nee -
Bijzonderheden
Product information "AM5 Heatspreader - AM5"
The AM5 High Performance Heatspreader is an upgrade heatspreader for AMD's Ryzen 7000 processors. The nickel-plated copper heatspreader features a 240 percent larger diamond-milled precision surface. This increased surface area over the original heatspreader allows for maximum heat dissipation with air and water coolers, while precision milling ensures extremely low surface roughness for best contact with the heat sink.
Replaces SAM and heatspreader
240% larger surface area (22 cm²)
Made of nickel-plated copper
Precision diamond milled surface
Compatible with air and water coolers
Only for delidded CPUs!
The nickel-plated surface of the AM5 High Performance Heatspreader is compatible with traditional thermal pastes and gallium-based liquid metals. The nickel forms a barrier layer between the liquid metal and the copper cooler, so liquid metal does not diffuse into the copper and alloying is minimized. As a result, multiple applications of liquid metal are generally not necessary. For the most maintenance-free system possible, a KryoSheet graphene thermal pad can be used as the thermal interface between the CPU and the AM5 High Performance Heatspreader. Since KryoSheet pads are electrically conductive, a cover is included to protect the electronic components on the CPU package.
Ryzen 8X00G Compatibility
Attention: The AM5 High Performance Heatspreader is NOT COMPATIBLE with the APUs of the Ryzen 8000G series! For more information on the compatibility of the AMD Ryzen 5 8500G, AMD Ryzen 5 8600G and AMD Ryzen 7 8700G with our products, please watch the following video: “AMD Ryzen 8000 Delidded - Liquid Metal Changes Everything!”
Scope of delivery
1x AM5 high performance heatspreader
4x UNC 6-32 1/4" pan head screws
1x hexagon socket wrench 5/64"
1x Insulation sheet
