Software-update: KiCad 10.0.6

Versie 10.0.6 van KiCad is uitgebracht. KiCad is een verzameling opensourceprogramma's waarmee elektronische schema's en printplaatlay-outs ontworpen kunnen worden. Verder kan het een bill of materials, Gerber-bestanden en een 3d-weergave van het pcb en de componenten maken. KiCad beschikt over een uitgebreide bibliotheek van componenten, inclusief het symbool, de footprint en 3d-modellen. Een Spice-simulator ontbreekt evenmin. De changelog voor deze uitgave kan hieronder worden gevonden.

General

• Fix crash when automatically saving freed document.
• Fix child node memory leak when deleting rule check items.
• Compact rule check handle vector during model rebuild to recover unused memory.
• Fix grid readout in status bar for footprint wizard and viewers. #24898
• Enforce per instance group transfer for shared sheets when update between schematic and board. #24956
• Bound local history walks to the project directory.
• Show a new project library without restarting. #24872
• Don’t pop a system error dialog when a file can’t be archived.
• Allow items to be added to a subgroup. #25023
• Correctly draw line styles on Bezier curves. #25110
• Fix properties panel tooltips repeating the field name. #25132
• Improve status bar layout for drawing main windows.
• Fix status bar field width issues.
• Fix plugin content manager dialog selection issue.
• Only escape tildes when they could be interpreted as markup when importing Eagle files. #25193
• Use local monitor for refresh rate capping.
• Reduce studder when refreshing canvas. #25014
• Fix hatched shapes plotting with no fill pattern. #25177
• Correct dead re-entrancy guard in request information update check. #23988
• Fix embedded files deleted by repeated setup dialog commits. #24998
• Fix DXF export of arc containing outlines. #16051
• Fix crash when moving editor windows between different monitors. #24036
• Keep a chosen print-to-file destination between prints. #24954
• Keep keyboard focus on dialogs so escape key closes dialog. #23647
• Resolve old version environment variables in configuration paths. #23120
• Don’t attempt contact disabled HTTP library rows. #24855
• Honor "Pan left/right with horizontal movement" setting. #24907
• Avoid saving .kicad_prj and .kicad_prl files when no changes have been made. #24402
• Fix crash when opening project from PDM system on local server. #21557
• Prevent dropping of repeated key bindings. #25073
• Restore old PDF plotting of text when outline fonts aren’t embeddable. #25228

Schematic Editor

• Ensure unique sheet names when placing design blocks as sheets. #24958
• Ensure unique group names when pasting named groups. #24957
• Propagate variant edits to all units of a multi-unit symbol. #24943
• Don’t try to convert "Sim.Library" content to URL.
• Don’t create or save variant records with no differences. #24858
• Fix X prefix check case for rectangle body color fill when importing from LTSpice.
• Prefer .include directives instead of "Sim.Library" when importing from LTSpice.
• Fix missing junctions at four-wire stub crosses.
• Convert PWL file=…​ sources to ngspice compatible devices.
• Tolerate misconfigured database properties columns. #23532
• Resolve missing symbol folders by basename fallback on LTSpice import.
• Convert .tran directives to ngspice-compatible form on LTSpice import.
• Honor SpiceOrder when assigning imported LTSpice pin numbers.
• Accept stacked pin numbers in jumper pin groups. #25063
• Honor jumper groups that name a stacked pin’s contacts.
• Use the job’s variant for the symbol fields BOM preview. #24915
• Don’t re-enter footprint reload in footprint assignment tool while one is running. #24999
• Un-highlight a sheet when the move cursor leaves it. #25104
• Keep a junction dot’s color and size when its wire is dragged. #25134
• Show a warning for a library that could not be loaded. #25166
• Properly resolve text variables in design variant fields.
• Keep a junction dot’s color and size when aligning to grid.
• Rename symbol properties with differing case identical spellings rather the deleting them.
• Sort design blocks alphabetically in the design blocks panel.
• Respect footprint selections in symbol choose from recently used items. #21163
• Fix pin numbers sitting too far from pin.
• Fix inverted field justification set from the properties panel. #25262
• Fix crash when sheet being dropped into itself. #25202
• Fix inherited field reorder crash. #25248
• Fix symbol angle orientation on Altium import. #24843
• Don’t report unloaded library table rows as load errors. #22764
• Connect a label wires preferentially with directive. #19951
• Prevent hierarchical bus labels from losing their bus color when moved. #25103
• Fix crash when closing editor window. #23738
• Push symbol fields table edits to every path of a shared sheet. #25112
• Sanitize room name in the Allegro netlist export.
• Flush queued log messages before early startup modal dialogs.

Symbol Editor

• Refresh library tree after symbol description change. #23642
• Correctly remove all alternate body styles. #25004
• Fix null pointer crash in library buffer. #24970
• Fix crash when editing multiple pins. #25280

Simulator

• Fix invalid netlist shown for FFT analysis tabs. #24978
• Allow escaped quotes in simulation parameter values. #19223
• Fix crash on exit after running a simulation.
• Report a zero AC magnitude as no value not 0 dB. #15265
• Allow a bus junction to fork at a wire-to-bus entry root. #24134
• Redisplay the schematic after a top-level sheet is deleted. #24870

Board Editor

• Account for copper-to-hole clearance in via gap when routing differential pairs. #21623
• Speed up layer and high-contrast switching.
• Speed up curved ratsnest with adaptive tessellation.
• Improve zone fill performance with continuous dependency graph fill and lock-free zone bounding box cache.
• Remove redundant predicate evaluation to improve DRC performance.
• Parallelize DRC providers and make the error cap thread safe.
• Improve DRC performance by spatially indexing footprint courtyards for intersection testing.
• Improve custom design rule performance.
• Stop false DRC errors on net-tie footprints. #24974
• Keep selection expansion inside the entered group. #24967
• Keep unrelated routing when applying a design block layout. #24944
• Allow nested sheets and groups as multichannel placement areas. #24964
• Include channel-local routing in multichannel sheet rule areas. #24983
• Don’t fill through the holes of a higher priority hatched zone. #24935
• Fix false creepage path through overlapping circular cutouts. #24885
• Don’t emit empty rules on Eagle import.
• Resolve footprints after non-KiCad project import.
• Make BOARD::get_layer_name() return the correct layer ID. #25131
• Properly overlap zone merges correctly when affected by a higher priority zone of a different net. #23790
• Keep a table in place when it is mirrored or flipped.
• Swap a table rows when table is flipped top to bottom.
• Fix clicking on a rotated table.
• Tilt a rotated table the right way when it is flipped.
• Accept the old Origin X/Y property names in custom rules. #24942
• Fix crash exporting ODB++ with a knockout text box. #25074
• Keep each via’s own size when editing several vias at once. #25100
• Don’t show rounded rectangle options in shape properties dialog for Bezier curves. #25120
• Fix router crash when highlighting a collision with a front/inner/back via. #25139
• Do not allow table editing in multi-channel tool.
• Length tuning now follows the net through in-line pads. #24737
• Reload footprint libraries that changed on disk.
• Fix crash pressing "Refresh" in the footprint library browser.
• Fix router posture optimization.
• Allow point objects in groups.https://gitlab.com/kicad/code/kicad/-/issues/23715[#23715]
• Fix optimization of dragged tracks.
• Fix missing copper rings on a differential pair via.
• Copy pad zone connection settings when repeating a multi-channel layout. #25244
• Keep blind and buried via colors after pressing escape key. #25108
• Plot an empty knockout text box instead of dropping it. #25225
• Don’t report on netclasses that don’t match.
• Fix use-after-free crash.
• Prevent rule area to silkscreen item distance violation from being inadvertently flagged. #24177
• Match un-annotated footprints in design block layout. #24585
• Properly escape double quoted fields on Specctra DSN export. #24946
• Prevent duplicate and empty footprint reference designators on Specctra DSN export. #24947
• Quote layer names with spaces and parenthesis on Specctra DSN export. #24948
• Correctly position footprint origin and keepouts on Altium import. #24847
• Fix crash while routing with (F) / attempt to finish. #24985
• Keep differential pair tuning within width runs. #23550
• Count back-drilled holes in the drill report. #25021
• Fix Eagle board import footprint through hole pad issue. #23982
• Fix reversed layers in back drill file names. #23452
• Quote the entered hole-to-hole rule in DRC violations. #22267
• Fix teardrop spike on custom pads whose anchor is far from the copper. #23311
• Fix inner diameter of ODB++ donut symbol for unfilled circles. #25089
• Honor DNP and BOM exclude for Gerber X3. #25010
• Give imported tuning patterns their baseline on Altium import. #24654
• Avoid user & system reference field collisions on Allegro import. #25219
• Prevent footprint from excluding itself in keep-out zone rules. #24924
• Preserve ${Class:X} for custom DRC selectors. #23905
• Always write "LineDesc" section for lines, arcs, and polylines on IPC-2581 export. #25149
• Initialize the via soldermask field on IPC-365 export.
• Fix crash when opening zone manager. #25284, #23951, and #22440
• Fix DRC crash. #25298
• Respect a hatched zone’s clearance inside its own border. #24935

3D Viewer

• Skip triangles with out-of-range face indices.
• Removed hole from capped vias. #23370
• Fix broken custom toolbars. #25035
• https://gitlab.com/kicad/code/kicad/-/commit/73997fb9acf3e31eb20afbbb9c45a9b99ad856dcHandle solder mask expansion for plated copper calculation].
• Don’t call OpenGL functions from if OpenGL wasn’t initialized yet.
• Fix inconsistent dielectric sublayer names when exporting IPC-2581. #25149
• Put via pads in a set when exporting IPC-2581. #25149
• Write a text box border as its own Features item when exporting IPC-2581. #25149
• Don’t write Features for text with no glyphs on IPC-2581 export. #25149
• Don’t crash when exporting a board with no outline to IPC-2581. #25149
• Report warnings on IPC-2581 export. #25149
• Knock out paste/mask layers when they’re clearly null. #25218

Page Layout Editor

• Fix hang incrementing labels containing non-ASCII characters. #25299

Job Sets

• Don’t save/restore output text field value in run log dialog. #25169
• Store the 3D export job’s component and net filters. #25107

Command Line Interface

• Use per-variant field values in multi-variant BOM export. #24936

Linux

• Ensure drop down menu list is not stays open after mouse click release on Wayland. #24418
• Clear PYTHONHOME/PYTHONPATH for legacy BOM generators in AppImage.
• Ensure date picker dialog control updates with current date. #24400

macOS

• Fix gerber files grayed out in the open dialog.
• Fix plugin manager crash. #23947

Windows

• Speed up simulator frame log reporting.
• Turn on segment heap for improved memory management.

IPC API

• Improve plugin identifier validation regular expression.
• Add parent field to board types.
• Add flip board item command.
• Expand stackup parameters. #24182
• Fix pad orientation loss after moving footprint. #25199
• Fix board view flip setting. #24122
• Fix crash deleting an item after a group referencing it was created in a rolled back commit. #25314

Versienummer	10.0.6
Releasestatus	Final
Besturingssystemen	Linux, macOS, Windows 10, Windows 11
Website	KiCad
Download	https://kicad.org/download
Licentietype	GPL
