Er zijn geen actuele prijzen bekend van dit product. De laatst bekende laagste prijs was € 189,- op 3 april 2024.
Specificaties
Belangrijkste specificaties
-
Socket
1200 -
Moederbordchipset
Intel B560 -
Form Factor
Mini-ITX -
Geheugentype (moederbord)
2x DDR4 -
Verbinding (wlan)
Wi-Fi 1 (802.11a), Wi-Fi 2 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) -
Ethernet (RJ45)
1x Ethernet 1Gbps
Belangrijkste specificaties
-
Socket
1200 -
Moederbordchipset
Intel B560 -
Form Factor
Mini-ITX -
Geheugentype (moederbord)
2x DDR4 -
Verbinding (wlan)
Wi-Fi 1 (802.11a), Wi-Fi 2 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) -
Ethernet (RJ45)
1x Ethernet 1Gbps
Verkrijgbaar sinds: 7 april 2021
Alles openen
Socket en CPU
-
Socket
1200
Form factor, bios en chipset
-
Form Factor
Mini-ITX -
Moederbordchipset
Intel B560
Geheugen
-
Geheugentype (moederbord)
2x DDR4 -
Maximum grootte werkgeheugen
64GB -
Opmerkingen geheugen
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- 11th Gen Intel® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 4600+(OC)*
- 10th Gen Intel® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 4400+(OC)*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel® Extreme Memory Profile (XMP) 2.0
*11th Gen Intel® Core™ (i9/i7/i5) support DDR4 3200 natively; Core™ (i3), Pentium® and Celeron® support DDR4 2666 natively.
10th Gen Intel® Core™ (i9/i7) support DDR4 2933 natively; Core™ (i5/i3), Pentium® and Celeron® support DDR4 2666 natively.
**Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
Opslag
-
Hardeschijf bus (intern)
1x M.2 (PCI-e 4.0 x4 + SATA), 4x SATA-600 -
Opmerkingen opslag
- 4 x SATA3 6.0 Gb/s Connectors, support Intel® Rapid Storage Technology 18, NCQ, AHCI and Hot Plug*
- 1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4 x4 (64 Gb/s) (with 11th Gen Intel® Core™ Processors) or Gen3 x4 (32 Gb/s) (with 10th Gen Intel® Core™ Processors)**
*If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
**Supports NVMe SSD as boot disks
Supports ASRock U.2 Kit - M.2 op CPU WEL op cpu
Uitbreidingsslots
-
Uitbreidingsslots
1x M.2, 1x PCI-e 4.0 x16 -
Totaal PCI-e x16
1x -
Opmerkingen uitbreidingsslots
11th Gen Intel® Core™ Processors
- 1 x PCI Express 4.0 x16 Slot*
10th Gen Intel® Core™ Processors
- 1 x PCI Express 3.0 x16 Slot*
- 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac PCIe WiFi module (on the rear I/O)
*Supports NVMe SSD as boot disks
Netwerk
-
Ethernet (RJ45)
1x Ethernet 1Gbps - Netwerkcontroller Intel I219V
- Netwerkcontroller(s) Intel I219V
Wifi en bluetooth
-
Verbinding (wlan)
Wi-Fi 1 (802.11a), Wi-Fi 2 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) -
Bluetooth
Bluetooth 4.2
Aansluitingen
- USB/TB intern (front) 1x 9-pins USB 2.0 header, 1x 19-pins USB 3.2 (G1, 5Gbit/s) header, 1x USB-C 3.2 (G1, 5Gbit/s) header
-
USB/TB extern
2x USB 2.0 type-A, 2x USB 3.2 (Gen1, 5Gb/s) type-A -
Video uit
1x DisplayPort, 1x HDMI - Totaal video-uitgangen 2
- Hoogste HDMI versie HDMI 2.0
- Hoogste DisplayPort versie DisplayPort 1.4
- Overige aansluitingen 1x PS/2
(Fan) headers
- Headers (fan/water) 3x 4-pins (totaal)
-
(default) Fanconfiguratie
The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power.
The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
RGB
- RGB-headers 1x 3-pins (ARGB)
-
LED verlichting
Audio
- Audio kanalen 8 (7.1)
- Audio-aansluitingen 2x Analoog (uitgang), 1x Microfoon (ingang)
- Audiochip Realtek ALC897
Vrm
-
Type stroomvoorziening
Powerstages -
VCore-powerstages
50A -
Vrm-koeling
- Vrm-opmerkingen Controller: RT3609BE
Meer informatie
- Product ASRock B560M-ITX/ac
- Categorie Moederborden
- Merk ASRock
- Tweakers ID 1689846
- EAN 4710483933912
- SKU 90-MXBEZ0-A0UAYZ, B560M-ITX/ac
- Specs van de fabrikant Productinformatie
