Software-update: RivaTuner 2.07

Rivatuner heeft een upgrade naar versie 2.07 gekregen. De nieuwe versie kan vanaf deze pagina voor Windows gedownload worden. Rivatuner werd enkele jaren geleden ontwikkeld om Nvidia Riva TNT-videokaarten te tweaken, zoals het aanpassen van (verborgen) Directx- en Opengl-instelling en het overklokken van de geheugensnelheid en de gpu. In de loop der tijd zijn er diverse nieuwe tweakmogelijkheden bijgekomen en is er ondersteuning toegevoegd voor de overige videokaarten van Nvidia en de Radeon-serie van ATi. Wat er zoal in Rivatuner 2.07 is veranderd, kan hierbeneden gelezen worden:

Minor bugfixes:
  • Fixed default values for Direct3D Intellisample slider and "Clamp negative mipmap LOD bias" option.
  • State of global OSD visibility setting is no longer lost when any other option is being changed immediately after changing the global OSD visibility setting in the properties of bundled RivaTunerStatisticsServer application.
  • Minor UI and localization fixes.
What's new:
  • Added ForceWare 171.xx, 173.xx and 174.xx drivers families support.
  • Updated databases for Detonator and ForceWare drivers. Added databases for ForceWare 169.09, 169.13, 169.17, 169.21, 169.25, 169.28, 169.32, 169.38, 169.39, 171.16, 171.17, 171.23, 173.65, 173.80, 174.12, 174.13, 174.16, 174.23 and 174.31.
  • Added Catalyst 7.11, 7.12, 8.1 and 8.2 drivers detection. Please take a note that both Catalyst 8.1 and 8.2 share the same binary file versions, so both Catalyst 8.1 and 8.2 will be detected as Catalyst 8.1 or newer.
  • Updated Catalyst 7.11, 7.12, 8.1 and 8.2 certified SoftR9x00 patch script (for Windows 2000/XP drivers only).
  • Updated PCI DeviceID database for both ATI and NVIDIA graphics processors. Added PCI DeviceIDs for RADEON 2600XT AGP, RADEON 2900GT, RADEON HD 3870 X2 and GeForce 8800GTS 512 SKUs. Please take a note that RivaTuner doesn't provide official Crossfire support, so RADEON HD 3870 X2 support can be limited to single GPU functionality under certain conditions.
  • Unlocked previously available experimental RV635 graphics processors support. Thanks to Andrey Vorobiev for testing RivaTuner with ATI RADEON HD3650.
  • Added experimental G94 graphics processors support. Thanks to Andrey Vorobiev and Hilbert Hagedoorn for testing RivaTuner with NVIDIA GeForce 9600GT.
  • Added powerful built-in task scheduler module. Task scheduler has been designed as more flexible and more programmable replacement for the previously available programmable monitoring thresholds technology, providing you the following functionality:
    • Ability to automate startup of any desired application (e.g. RivaTunerStatisticsServer) or launch item (e.g. combination of fan and overclocking profiles or shortcut to RivaTuner's hardware monitoring module GUI) on specified schedule. The following schedule types are currently supported:
      • Run task at Windows startup. This schedule type can be used as a replacement for RivaTuner's own "Run ... at Windows startup" options by means of loading desired overclocking / fan / color profiles as well as for programming additional sophisticated tasks (e.g. for programming VRM module at OS startup by means of RivaTuner's command line interface for direct access to GPU registers).
      • Run task at RivaTuner startup. This schedule type can be used to automate startup of some applications, which you need to run in conjunction with RivaTuner only (e.g. RivaTunerStatisticsServer) or for activating some GUI windows (e.g. Hardware monitoring window) at RivaTuner startup.
      • Run task at RivaTuner shutdown. This schedule type can be used to automate shutdown of some applications, which you need to run in conjunction with RivaTuner only (e.g. RivaTunerStatisticsServer).
      • Run task on entering suspended mode. This shedule type can be used as a workaround for some driver and hardware-specific issues (e.g. some old ATI display adapters don't resume from suspended mode properly when entering it in overclocked state).
      • Run task on leaving suspended mode. This schedule type can be used as a replacement for RivaTuner's own "Restore ... after suspended mode" options by means of loading desired overclocking / fan / color profiles as well as for programming additional tasks (e.g. for reconnecting RivaTuner to G15 LCD after resuming from suspended mode).
      • Run task on hardware monitoring threshold event. This schedule type replaces previously available programmable monitoring thresholds and it can be used for programming different dynamic overclocking / fan control / gamma correction algorithms depending on different monitored parameters (e.g. dynamic fan control depending on temperature threshold or dynamic clock control depending on hardware acceleration threshold).
      • Run task on hardware monitoring range event. This schedule type provides you alternate way for programming different dynamic overclocking / fan control / gamma correction algorithms depending on different monitored parameters, which can be more convenient in case of using multiple thresholds (e.g. when you define dynamic fan control rule based upon 3 or more thermal zones).
    • Standard safety measures, allowing you to skip scheduled tasks if necessary (e.g. if you have programmed loading a profile with too agressive overclocking at Windows startup or if you have programmed RivaTuner to close itself at startup). You can hold <Ctrl> key after logging in Windows to skip RivaTuner's tasks scheduled to be started with Windows or you can hold <Ctrl> key during RivaTuner startup to skip RivaTuner's tasks scheduled to be started with it.
    • Better thresholds visualisation features comparing to the previously available technology:
      • Now threshold visualitation can be optionally disabled in the corresponding schedule properties.
      • Now programmed threshold crossing direction is visualised on the graph.
  • Improved built-in launcher module:
    • Predefined applicaitons list has been removed from the regular launch item editor window. Now the list of predefined applications is integrated directly in file system browser window accessible via the "Browse" button.
  • Improved experimental SLI support. Please take a note that I have no SLI rig for testing and development, so all SLI related improvements are done blindly and RivaTuner still doesn't provide official SLI support:
    • Added workaround for NVAPI GPU handle leak issue under Windows XP. It is no longer necessary to disable NVAPI usage and loose independent shader domain overclocking features to get multi-GPU overclocking working under Windows XP.
    • Added driver-level NVAPI multi-GPU fan control. Now RivaTuner synchronically applies the same driver-level fan settings to all graphics processors in SLI configuration. Please take a note that it applies to driver-level fan control only, low-level fan tweaks such as custom automatic fan control rule can be applied to the physically selected display adapter only.
    • Now you can disable driver-level NVAPI multi-GPU clock control and fan control via NVAPIMultiGpuClockControl and NVAPIMultiGpuFanControl registry entries if necessary.
  • Improved compatibility with Vista UAC:
    • Now RivaTuner can be started at Windows Vista startup via special wrapper application, which doesn't require full administrative privileges and which is not being blocked by UAC's startup infrastructure. Please take a note that RivaTuner itself is still the administrative application so it still requires your evaluation during each startup; wrapper application usage just changes the way of evaluating RivaTuner launch during each OS startup. Now you will see standard UAC evaluation message when Windows starts instead of seeing a message about blocked application in the tray. Take a note that by design of UAC evaluation messages automatically get canceled after 120 seconds timeout, so avoid using new mode if your system is booting itself without your control. The previous startup mode can be also enabled via setting RivaTunerWrapperUsageBehavior to 0.
    • Added power user oriented RequestedExecutionLevel registry entry, allowing changing RivaTuner's execution level without editing the manifest file. This feature can be useful for those who schedule RivaTuner to be started with full administrative rights via other applications like Vista Scheduler.
  • Improved RV6xx graphics processors family support:
    • Extended list of tweakable automatic fan speed control rule parameters for RV6xx fan controllers. Now besides editing previously available thermal lookup RivaTuner can be also used to alter automatic fan speed control mode and select either temperature transfer function mode or thermal lookup mode as well as tweak parameters for temperature transfer function mode (minimum duty cycle, minimum temperature, temperature slope etc.). These settings allow power users to fix infamous HD 38x0 BIOS automatic fan control issues without flashing so called fan fix BIOS.
    • Added direct access to ATI RADEON HD 2xxx/3xxx flashrom chips. Now you can use RivaTuner's /BI command line switch for dumping VGA BIOS image on ATI RADEON HD 2xxx/3xxx family display adapters.
    • Now RivaTuner uses additional reference dividers to provide correct core clock frequency reading on ATI RADEON HD 3870 series after flashing BIOS with PLL VCO divider fix.
    • Now RivaTuner restores default clocks when disabling low-level hardware overclocking by means of the driver's PowerPlay table reset if possible.
  • Updated RivaTunerStatisticsServer v2.5.0 bundled utility:
    • Now the server supports %FRAMERATE% macro in the OSD text slot, allowing it to display application specific framerate and 3D API usage information instead of shared framerate and 3D API usage information directly sent to OSD by the client application. Power users may prevent RivaTuner from using %FRAMERATE% macro via the EnableFramerateMacroEncoding registry entry.
    • Now the server is able to detect client specific framerate rendering requests and disable own statistics rendering in this case to prevent duplicating framerate info in the OSD.
    • Added Direct3D10 (for non-multisampled frame buffers only) screen capture support.
    • Extended list of supported screen capture formats. Now the server is able to capture screenshots in *.jpg and *.png formats for Direct3D9 and Direct3D10 applications. Please take a note that these formats can be also specified while capturing desktop, DirectDraw, Direct3D8 ans OpenGL screenshots, but in fact it will result in storing .bmp file with *.jpg or *.png extensions.
    • Now the server is able to capture multiple screenshots at once if multiple 3D applications are running simultaneously.
    • The server's startup routine is no longer trying to precache Direct3D10 runtime info under Windows XP to reduce startup time under this OS and avoid stealing the focus from other running applications.
    • Improved compatibility with applications using multithreaded 3D engines. Reduced risk of crashing the server when unloading it while such 3D application (e.g. Lost Planet : Exteme condition) is running.
    • Now the server is able to provide per-frame frametime statistics of any 3D application to automated third party benchmarking applications (e.g. TPUBench) via the named pipe.
    • Updated list of pseudo 3D applications.
  • Improved hardware monitoring module:
    • Now "Framerate" graph shows framerate from the focused application if there are multiple 3D applications running simultaneously.
    • Added SEH for clock calculation routines for better protection against incorrect hardware emulation.
    • Changed default Core/Memory clock graph ranges from 1.5GHz to 2GHz.
    • Improved NVThermalDiode.dll hardware monitoring plugin. Now the plugin supports G84, G86, G92 and G94 thermal diodes. Please take a note that G92 thermal diode calibration logic seem to be broken in this GPU, that is why the plugin uses approximated conversion of raw G92 thermal diode reading to temperature similar to ASUS SmartDoctor software. Such approximated conversion can be really inaccurate, that is why it is strongly recommended to use the plugin only on non-reference design G92 based display adapters not equipped with external ADT7473 sensor.
  • Improved driver-level fan control module:
    • Now driver-level fan profiles can be used for storing and recalling automatic fan control mode.
  • Now all low-level profiles are linked with target display device by physical display adapter location identifier instead of logical display adapter name. Due to this change all previously created low-level profiles will be invisible to new version and you will need to recreate them.
  • Improved generic RivaTuner file format. Now all RivaTuner's files based upon this format (i.e. database build scripts, databases, presets and patch scripts) can use global autoincremental indices similar to previously supported local autoincremental indices, which greatly simplify large files editing and updating.
  • Improved context help source format. Now all context help topics added to new version are represented by separate .RTF file to simplify context help translation process for third-party localization packs creators.
  • MMIO protection fallback warning is no longer displayed on any MMIO range allocation failure, unprotected MMIO failure warning message has been added.
  • Now power users may customize the range of scanned PCI buses to allow using RivaTuner with some sophisticated mainboards having more than 16 physical PCI buses. By default RivaTuner scans just the first 16 PCI buses for display adapter presence, however power users may extend the range of scanned PCI buses using the MaxPCIBusNum registry entry.
  • Protected tabs (i.e. the tabs like "Main" in the main property sheet that cannot be hidden) are now displayed in preview area of the tab order customization window.
  • Updated Easter Eggs.
  • Minor UI changes and improvements.
RivaTuner - overclocking
Versienummer 2.07
Releasestatus Final
Besturingssystemen Windows 2000, Windows XP, Windows Vista, Windows Vista x64
Website Guru3D
Bestandsgrootte 2,26MB
Licentietype Freeware

Door Robin Vreuls


03-03-2008 • 15:46

8 Linkedin Google+

Submitter: Bullus

Bron: Guru3D


Reacties (8)

Wijzig sortering
Een hele list of changes, eindelijk is de fout er uitgehaald dat de shadermax balk tot 1,5Ghz liep. nu kan ik fatsoenlijk zien hoe veel de 1890 shaders overklok is tov de 1500mhz stock!
Verder een heerlijk programma, nu nog een build in stresstest, zoals AtiTool, en het programma is af. (verbeterde sli ondersteuning terzijde, aangezien er maar een klein percentage mensen is wat daadwerkelijk sli draait)
Ondersteuning voor tri-sli zou ik graag zien.
Nu is er maar 1 manier en dat is elke kaart afzonderlijk testen met rivatuner en vervolgens het bios flashen.
Eenmaal getest is dit niet zo'n ramp maar met waterkoeling is dit wel een crime en zou rivatuner met ondersteuning een stuk makkelijker zijn.

Grappig : Updated easter eggs

[Reactie gewijzigd door justifire op 3 maart 2008 16:01]

Ik heb dit programma jarenlang met veel plezier gebruikt. Maar sinds ik mijn 8800GT heb, gebruik ik Nibitor om de clockspeeds en voltages van mijn kaart aan te passen. Gewoon een zelfgemaakt BIOS erin flashen en gaan met die banaan. Na het softwarematig verhogen van de Vgpu met 0,05V krijg ik de core stabiel op 780MHz. Dit was voorheen slechts 740MHz.
start het programma nu eindelijk op in windows vista zonder dat je eerst zo een irritant schermpje krijgt. ik weet dat ik dat hele systeem kan uitzetten. maar toch
werk het nu ook op nvidia 8400series en hoger dat je de shader klok kan aanpassen
Op de desktop werkt het wel namelijk
ik had problemen met mn SLI setup, als ik 1 kaart overclockte ging die andere wel mee, verhoogde ik de fan snelheid met 1tje ging de andere niet mee.. resultaat dat mn 2de kaart 77 graden werd op stock speeds omdat ik de fan niet kon verhogen

gelukkig is die bug er nu uit gefixed en draait mn SLI setup nu weer op 600 / 1800 met de fan op 90 % :)
Er bestaat een edit-knop ;)
