BijzonderhedenMinimum System Requirements
• macOS: 10.8 Class Compliant
• PC: Windows 7, Windows Driver
• Standard USB 2.0 or USB-C Port
Mic Input 1 (balanced XLR)
FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.1 dB)
DYNAMIC RANGE: 104 dB (A-weighted)
SIGNAL-TO-NOISE RATIO: 104 dB (+1.0 dBu, A-weighted)
THD+N: 0.003%
PREAMP EIN: -128 dBu (max gain, 150 Ω source, A-weighted)
MAX INPUT LEVEL: +1.5 dBu
GAIN RANGE: 55 dB
Line Input 1 (balanced 1/4" [6.35 mm] TRS)
FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB)
SIGNAL-TO-NOISE RATIO: 101 dB (1 kHz, +4 dBu, A-weighted)
THD+N: 0.003%
MAX INPUT LEVEL: 16 dBu
GAIN RANGE: 55 dB
Inst Input 2 (unbalanced 1/4" [6.35 mm] TS)
FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.05 dB)
DYNAMIC RANGE: 100 dB (A-weighted)
SIGNAL-TO-NOISE RATIO: 102 dB (+ 4 dBu, A-weighted)
THD+N: 0.004%
MAX INPUT LEVEL: 6 dBu
INPUT IMPEDANCE: 1 MΩ
GAIN RANGE: 24 dB
Main Outputs, L and R (balanced, differential 1/4" [6.35 mm] TRS)
FREQUENCY RESPONSE: 20 Hz – 20 kHz (+0.06 dB)
DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO: 102 dB (A-weighted)
THD+N: 0.005%
MAX OUTPUT LEVEL: +7 dBu (1 kHz, -1 dBFS)
