MSI MAG Z590 Torpedo

Populaire specificaties
Socket	1200
Moederbordchipset	Intel Z590
Form Factor	ATX (Standard)
Geheugentype (moederbord)	4x DDR4
Ethernet (RJ45)	1x Ethernet 1Gbps, 1x Ethernet 2.5Gbps
Uitbreidingsslots	2x PCI-e 3.0 x1, 2x PCI-e 4.0 x16

Socket en CPU
Socket	1200
Klokfrequentie	0Hz
Maximale turboklokfrequentie	0Hz
Maximaal TDP processor	0W

Form factor, bios en chipset
Form Factor	ATX (Standard)
Moederbordchipset	Intel Z590

Geheugen
Geheugentype (moederbord)	4x DDR4
Maximum grootte werkgeheugen	128GB

Opslag
Hardeschijf bus (intern)	2x M.2 (PCI-e 3.0 x4 + SATA), 1x M.2 (PCI-e 4.0 x4), 6x SATA-600
Raid-modi	0, 1, 5, 10

Uitbreidingsslots
Uitbreidingsslots	2x PCI-e 3.0 x1, 2x PCI-e 4.0 x16
Totaal PCI-e x16	2x
Opmerkingen uitbreidingsslots	3x M.2 slots (Key M) M2_1 slot (From CPU) Available only on 11th Gen Intel® CPU Supports up to PCIe 4.0 x4 Supports 2242/ 2260/ 2280/ 22110 storage devices M2_21 & M2_3 2 slot (From Z590 chipset) Supports up to PCIe 3.0 x4 Supports SATA up to 6Gb/s Supports 2242/ 2260/ 2280 storage devices Intel® Optane™ Memory Ready 3 Supports Intel® Smart Response Technology for Intel Core™ processors SATA2 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.SATA5 & SATA6 will be unavailable when installing M.2 SSD in the M2_3 slot.Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. 2x PCIe x16 slots 1x PCIe 3.0 x16 slot (from CPU) Support up to PCIe 4.0 for 11th Gen Intel® CPU Support up to PCIe 3.0 for 10th Gen Intel® CPU PCI_E3 (From Z590 chipset) Support up to PCIe 3.0 x4 2x PCIe 3.0 x1 slots (From Z590 chipset)

Netwerk
Ethernet (RJ45)	1x Ethernet 1Gbps, 1x Ethernet 2.5Gbps
Netwerkcontroller	Intel I225-V
Tweede netwerkcontroller	Intel I219V
Netwerkcontroller(s)	I225-V, Intel I219V

Aansluitingen
Video uit	1x DisplayPort, 1x HDMI
Totaal video-uitgangen	2
Hoogste HDMI versie	HDMI 2.0a

(Fan) headers
Headers (fan/water)	7x 4-pins (totaal)

RGB
LED verlichting
LED kleur	Multi-color

Overige eigenschappen
Eigenschappen moederbord	AMD Crossfire

Audio
Audio kanalen	8 (7.1)
Audio-aansluitingen	4x Analoog (uitgang), 1x Digitaal Optisch (S/PDIF)
Audiochip	Realtek ALC4080

Garantie en bijzonderheden
Fabrieksgarantie	3 jaar carry in

Meer informatie
Product	MSI MAG Z590 Torpedo
Categorie	Moederborden
Merk	MSI
Tweakers ID	1684886
EAN	4719072800536
SKU	7D08-003R, MAG Z590 TORPEDO
Specs van de fabrikant	Productinformatie
