ASRock X299 Taichi CLX

Populaire specificaties
Socket	2066
Moederbordchipset	Intel X299
Form Factor	ATX (Standard)
Geheugentype (moederbord)	8x DDR4
Verbinding (wlan)	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ethernet (RJ45)	1x Ethernet 1Gbps, 1x Ethernet 2.5Gbps

Socket en CPU
Socket	2066

Form factor, bios en chipset
Form Factor	ATX (Standard)
Moederbordchipset	Intel X299

Geheugen
Geheugentype (moederbord)	8x DDR4
Maximum grootte werkgeheugen	256GB

Opslag
Hardeschijf bus (intern)	1x M.2 (PCI-e 3.0 x4 + SATA), 2x M.2 (PCI-e 3.0 x4), 10x SATA-600
Raid-modi	0, 1, 10

Uitbreidingsslots
Uitbreidingsslots	1x PCI-e 3.0 x1, 4x PCI-e 3.0 x16
Totaal PCI-e x16	4x
Opmerkingen uitbreidingsslots	If you install CPU with 48 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x8/x16/x8. If a M.2 PCI Express module is installed on M2_1 or M2_2, PCIE2 will downgrade to x4 mode. If M.2 PCI Express modules are installed on M2_1 and M2_2, PCIE2 will be disabled. If you install CPU with 44 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x4/x16/x8. If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled. If you install CPU with 28 lanes, PCIE1/PCIE2/PCIE3/PCIE5 will run at x16/x4/x8/x0. If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled. Supports NVMe SSD as boot disks

Netwerk
Ethernet (RJ45)	1x Ethernet 1Gbps, 1x Ethernet 2.5Gbps
Netwerkcontroller	Realtek RTL8125AG
Tweede netwerkcontroller	Intel I219V
Netwerkcontroller(s)	Intel I219V, Realtek RTL8125AG

Wifi en bluetooth
Verbinding (wlan)	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth	Bluetooth 5.0

Aansluitingen
USB/TB intern (front)	2x 9-pins USB 2.0 header, 1x 19-pins USB 3.2 (G1, 5Gbit/s) header, 1x Thunderbolt header, 1x USB-C 3.2 (G2, 10Gbit/s) header
USB/TB extern	2x USB 2.0 type-A, 4x USB 3.2 (Gen1, 5Gb/s) type-A, 1x USB 3.2 (Gen2x2, 20Gb/s) type-C

(Fan) headers
Headers (fan/water)	7x 4-pins (totaal)

RGB
LED verlichting
LED kleur	Multi-color

Overige eigenschappen
Eigenschappen moederbord	Dual BIOS

Audio
Audio kanalen	8 (7.1)
Audio-aansluitingen	5x Analoog (uitgang), 1x Digitaal Optisch (S/PDIF)
Audiochip	Realtek ALC1220

Meer informatie
Product	ASRock X299 Taichi CLX
Categorie	Moederborden
Merk	ASRock
Tweakers ID	1486691
EAN	4717677339765
SKU	90-MXBBH0-A0UAYZ
Specs van de fabrikant	Productinformatie
